English
Connection terminal (Back side)
HDMI OUT (ARC) - (Audio Return Channel)
1
For connection to the HDMI (ARC) input on your TV.
HDMI INPUT - HD 1 / HD 2 / HD3
2
For connection to the HDMI output on your digital devices.
OPTICAL IN (OPT)
3
For connecting to the optical audio output on your TV or digital device.
SERVICE CONNECTION
4
Use only for Canton customer service.
ETHERNET (LAN)
5
Connection to the Internet via Ethernet (RJ45) connector.
SUB OUT
6
To connect an external subwoofer.
COAXIAL (COX)
7
For connection to the digital coaxial audio output on your TV or digital device.
LINE L/R (AUX)
8
For connection to the analog line output on your playback device.
POWER INPUT
9
For connection to the mains supply.
