Controls
OSM (On-Screen-Manager) Controls
The OSM controls on the front of the monitor function as follows:
To access OSM press any of the control buttons ( , , -, +, NEXT).
Control Menu
EXIT Exits the OSM controls.
Exits to the OSM main menu.
Moves the highlighted area left/right to select control
CONTROL /
menus.
Moves the highlighted area up/down to select one of the
controls.
ADJUST -/+ Moves the bar left/right to increase or decrease the
adjustment.
Activates Auto Adjust function.
Enter the sub menu.
NEXT Moves the highlighted area of main menu right to select
one of the controls.
Resets the highlighted control to the factory setting.
RESET/MUTE
When no OSM menu is shown, the speaker sound will be
muted.
NOTE: When RESET is pressed in the main and sub-menu, a warning
window will appear allowing you to cancel the RESET function
by pressing the EXIT button.
Sound
VOLUME
Control the sound volume of speakers and
headphones.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen
brightness.
