POWER SUPPLY:

Rechargeable battery
„
Typ
„
Charge time
„
Min. battery life
„
Max. battery life
„
USB external power supply Battery charger
„
Network voltage
„
Frequency
„
Consumption
„
Voltage
„
Polarity
„
The BNC connectors are recessed to comply with safety standards. Take care to use compatible accessories.
A
B
6 x 1.2 V - LR6 or AA
NiMH
approx. 3h30
approx. 5h45
approx. 8h30 (1 channel deactivated, AC coupling)
98 V to 264 V
from 50 to 60 Hz
< 11 VA in operation
≅ 19 VA in fast battery charge
5 VDC
2 A
MEASUREMENT CHANNELS
A single press selects the channel (A or B) and opens the corresponding menu.
A double press deselects the channel.
External power supply (Jack plug)
Input Channel "B"
Input Channel "A"
