SPL Phonitor One d Bedienungsanleitung Seite 5

Headphones Output; 6.35 mm (1/4") TRS Jack
Wiring
Source impedance
Frequency range (-3 dB)
Noise (A-weighted, 600 Ω)
THD + N (0 dBu, 10 Hz – 22 kHz, 600 Ω)
THD + N (0 dBu, 10 Hz – 22 kHz, 32 Ω)
Max output power (600 Ω)
Max output power (250 Ω)
Max output power (47 Ω)
Fade-out attenuation (600 Ω)
Crosstalk (1 kHz, 600 Ω)
Reference: 0 dBu = 0,775V. All specifications are subject to change without notice.
Phonitor One d
Tip = Left, Ring = Right,
Sleeve = GND
20 Ω
10 Hz - 200 kHz
-97 dBu
0,002 %
0,013 %
2 x 190 mW
2 x 330 mW
2 x 400 mW
-99 dB
-75 dB
Internal Power Supply
Operating voltage for analog audio
Operating voltage for headphone amplifier
Operating voltage for relays
Operating voltage for digital audio
External Power Supply
AC/DC switching adapter
DC plug
Input
Output
Dimensions & Weight
W x H x D (width x height incl. feet x depth)
Unit weight
Shipping weight (incl. packaging)
+/- 17 V
+/- 19 V
+12 V
+3.3 V, +5 V
Mean Well GE18/12-SC
(+) pin 2.1mm; (-) outside ring 5.5mm
100 - 240 V AC; 50 - 60 Hz; 0.7 A
12 V DC; 1.5 A
210 x 49,6 x 220 mm /
8,23 x 1,95 x 8,66 inch
1,45 kg / 3,2 lb
2 kg / 4,4 lb
