SPL Phonitor One d Bedienungsanleitung Seite 2

1
Read the security advices on page 6!
2
Read the installation instructions of the included
external power supply on page 8.
3
Make sure that the power switch on the rear is set
to Off (Off = out position / ON = in position).
4
Connect the included power supply to the DC input
and an appropriate mains socket outlet.
5
Turn down volume.
6
Connect your headphone to the headphone output.
7
Connect your analog sources to the line inputs.
8
Connect your computer or mobile device to the USB
input.
2
9
Connect the line out to the inputs of your analog au-
dio device to benefit from the 32-bit Velvet Sound™
DA converter.
The level is unity gain, thus independent of the volume control.
10
Set the dip switch to your needs.
Dip switch 1 on/down = attenuate the headphone output by 10 dB.
Dip switch 2 = not connected
11
Switch the on Phonitor One d by pressing the power
button.
12
Choose an input.
13
Set the volume and the crossfeed to taste.
14
Have fun!
More information: SeriesOne.spl.audio
Phonitor One d
