PART NAMES

FRONT / BACK

1
2
3
4
5
6
7
8
1 Air Outlet
2 Handle
(2 Locations)
3 Sensor
(Internal)
•Dust Sensor
•Temperture / Humidity Sensor
•Odour Sensor
(KC-A60EU•KC-A50EU ONLY)
4 Water Tank
5 Humidifying Filter
INCLUDED
• Operation manual
• Slipper
1
2
3
10
11
12
13
×4
1 Main Unit Display
2 Front Monitor
3 Main Unit
(Shape of plug depends on country.)
6 Float
7 Humidifying Tray
8 Caster
(4 Locations)
9 HEPA Filter
(white)
Deodorizing Filter
Back Panel
(Pre-Filter)
Air Inlet
Power Cord / Plug
E-4
(Ref.E-5)
9
10
11
12
13
(black)
