PART NAMES

OPERATION PANEL

13 11
12 10
14

LIGHT SENSOR

When the Light Control
is set to "Auto", Front
Display and Cleanliness
Indicator will automatically
switch ON or OFF based
on room brightness.
(Page 12, 13)
9 7
8 6
FRONT DISPLAY
19 17
21 20
15
Detection range of Light sensor
NOTE
Do not install the product in the following places.
The Light Sensor may not sense correctly.
Directly under
a light fixture.
EN-6
*The illustration in this instruction manual is UA-KIL80E.
5 4
18
In shadow
2
3 1
