garantibeviset. På bagsiden af denne manual finder du en tegning med alle dele, der kan bestilles.
D
Miljø
For at undgå transportbeskadigelse leveres maskinen i en solid emballage. Emballagen er så
vidt muligt lavet af genbrugsmateriale. Genbrug derfor emballagen.
NL
Defekte og/eller kasserede elektriske eller elektroniske maskiner skal afleveres på
en genbrugsplads.
F
Garanti
E
Se venligst garantibetingelserne på garantikortet, som er vedlagt separat.
P
CE
KONFORMITETSERKLÆRING (DK)
(
I
Vi erklærer herved, udelukkende på eget ansvar, at dette produkt opfylder følgende
standarder eller standardiserede dokumenter
S
EN60745-1, EN60745-2-1 , EN60745-2-2, EN55014-1, EN55014-2
EN60335-1, EN60335-2-29 , EN61000-3-2, EN61000-3-3
SF
i henhold til følgende direktiver:
98/37/EØF, 73/23/EØF, 89/336/EØF
N
01-05-2006
ZWOLLE NL
DK
J.A. Bakker - van Ingen
CEO Ferm BV
Det er vores hensigt til stadighed at forbedre vores produkter, og vi forbeholder os derfor til
enhver tid retten til at ændre produktspecifikationerne uden forudgående varsel.
Ferm BV • Lingenstraat 6 • 8028 PM Zwolle • Holland
90
J. Lodewijk
Quality Manager Ferm Global
• Only use the battery block supplied in combination with this cordless drill/screwdriver
so as to avoid faults and/or risks to persons.
14. A damaged battery block or one that can no longer be charged must be disposed of as
special waste. Do not discard it with household waste.
15. Never throw the battery block onto a fire or into water. This will risk explosion!
Electrical safety
Always check whether your battery voltage matches that shown on the rating
plate. Also find out whether your mains voltage matches the input voltage of the
charger.
The battery charger is doubly insulated in compliance with EN60335; it therefore
does not require earthing.
When replacing old cables or plugs
Throw away old cables or plugs immediately as soon as new ones have replaced these. It is
dangerous to put the plug of a loose cable into the socket outlet.
3. MOUNTING ACCESSORIES
Always remove the battery before starting work.
Fitting and removing drill cutters
Fig. B
In addition to drill cutters, the tool can also accommodate screwdriver bits with a hexagonal
shaft.
•
Loosen the drill chuck (4) by rotating the hand-grip (9).
•
Insert the shaft of the drill cutter into the chuck.
•
Tighten the drill chuck so that the drill cutter is firmly clamped.
•
Rotate the drill chuck in the opposite direction when you wish to change the cutter.
Connecting and removing the battery
Fig. C
Ensure that the exterior of the battery block or tool is clean and dry before
connecting the charger.
•
Ensure that the direction reversing switch (6 Fig. A) is in the central position in order to
prevent the appliance from being switched on unexpectedly.
