Unit Scheme:
1. Handlebar * 2. Non-slip grips * 3. Handlebar * 4. Tube
front * 5. Handlebar adjustment * 6. Display and accelerator * 7.
Brake lever * 8. Light and bell control * 9. Foot support * 10.
Hydraulic brakes * 11. Led spotlight * 12 Base LEDs * 13. Shock
absorbers * 14. Charging port * 15. Kickstand * 16. Brake light * 17.
Lever to fold the frame * 18. Indicator selector button * 19. Blin-
king light
1
7
8
3
4
11
13
19
10
The scooter has front focus, base, brake and turn signal LEDs, it
can be activated from its control knob. See the Control Panel
section.
