KRAUSE RollTec 710307 Aufbau- Und Verwendungsanleitung Seite 8

Pos.
1 RollTec vertical frame
2
3
4
5
6 Safety-set M 5 x 65 mm
7 Safety-set M 5 x 85 mm
3. General assembly instruction
Mount the rail and diagonal braces to the rungs from above. Secure the braces with the
safety-sets directly next to the vertical tube of the vertical frame. (see image 1).
Image 1 Safety-set M5x65 / Brace
8
Bezeichnung
Castor
Platform
Diagonal brace
Rail brace
Art.-Nr.
715050
714107
711304
712707
712806
718860
718877
Anzahl
2
4
1
1
1
4
2
