8.1 CA MODE
The following text appears on the screen:
m 3 /h K1?
Airflow 1 selection (contacts between terminals K1 and +12V closed)
0000
Select each digit using
The following text appears on the screen:
m 3 /h K2?
Airflow 2 selection (contacts between terminals K2 and +12V closed)
0000
Select each digit using
The following text appears on the screen:
m 3 /h K3?
Airflow 3 selection (contacts between terminals K3 and +12V closed)
0000
Select each digit using
The following text appears on the screen:
PRESSURE
Pressure alarm is optional. Of you do not wish to set a pressure alarm select N(o), otherwise select Y(es) using
ALARM? N
ENTER to confirm.
If you selected N(o), the following text appears on the screen:
END SETUP
If you selected Y, the following text appears on the screen :
∆P FAN
Pressure alarm setup:
xxx Pa
Choice of allowed pressure increment (?Pa admitted on filter) at reference airflow
Select value using
INIT Pa
Pressure alarm setup:
REF? N
Definition of reference pressure at reference airflow (optional if previously carried out)
Selectionner Y(es) / N(o) using
If you selected N(o), the following text appears on the screen:
END SETUP
If you chose Y(es), the following text appears on the screen:
m /h INIT
3
Pressure alarm setup:
0000
Enter airflow to define reference pressure.
Select each digit using
Following texts appear alternatively on the screen and LED Alarm blinks:
Pa REF
Reference pressure initialisation busy....
INIT
xxxxm
3 /h
Display of actual pressure and airflow...
xxxx Pa
The setup is then completed.
END SETUP
, keys, then press ENTER to confirm.
, keys, then press ENTER to confirm.
, keys, then press ENTER to confirm
The setup is then completed.
, keys, press ENTER to confirm (digit by digit selection).
, keys then press ENTER to confirm.
The setup is then completed.
, keys and press ENTER to confirm (digit by digit selection).
