1.1.3. Connection to a DVD or video recorder

Just as the TV set, the DVD or video recorder is
connected to the receiver via a SCART connection.
Use the VCR SCART socket for this purpose (see
picture 8).
If you also have a video recorder connected to the
terrestrial antenna cable, this terrestrial antenna
connection should run fi rst from the receiver to the
video recorder and only from there to the TV set.
As in a case the audio and video signals have to be
modulated for high-frequency transmission on a UHF
channel, signal quality is not as good compared to a
connection with a SCART cable.
Picture 8

1.1.4. Connection to a Hi-Fi system

The audio quality of digital TV and radio programmes can
be enjoyed even more when reproduced through a Hi-Fi
system. To do this, use a RCA cinch stereo cable to connect
the sockets marked Audio L/R on the receiver to one of the
inputs of your Hi-Fi system marked either Line, Aux, Spare
or Extra (see picture 9).
Picture 9
If your Hi-Fi system is equipped with a digital audio input,, you
may use a digital RCA cinch cable to connect the electrical
(Coax) digital audio output of your receiver (socket DIGITAL
AUDIO COAX) to your Hi-Fi or Dolby Digital system. The
receiver is also equipped with an optical digital output. If
your Hi-Fi system is equipped with an optical audio input,
you may use an optical cable to connect your Hi-Fi system
to your digital receiver (see picture 10).
Picture 10
7
