Software Upgrade:
• Download Through RS-232 and USB
• Over The Air (OTA) Download
RF Modulator:
• TV standard: PAL (G/I/K)
• Frequency range: 47~862 MHz
USB 2.0 interface:
• 2 USB 2.0 ports
• Bus access cycle speed: Up to 12MB/s
• USB host: 1 port, USB-A type
• USB device: 1 port, USB-B type
Rear panel:
• 2 Front-End (input connector): 2x F-Connector
• 2 Front-End (Loop Through Output connector): 2x F-Connector
• RF Modulator (RF input connector): 1 Type IEC169-2
• RF Modulator (Loop Through Output connector): 1 Type IEC169-2
• TV SCART connector: CVBS (output), RGB (output), L&R Audio (output), S-Video (output)
• VCR SCART connector: CVBS (input & output), RGB (input), L&R Audio (input & output), S-Video (output)
• Digital Audio SPDIF: 1 Coaxial, 1 Optical
• CINCH (RCA): Audio – L&R, Video – CVBS
• S-Video: Mini-DIN (Female)
• Digital Audio SPDIF: Coaxial and Optical
• Serial Port: RS-232C (Female, DB-9)
Front panel:
• 11 Keys for Input and Navigation
• 10-digit Vacuum Fluorescent Display (VFD)
• 1 Power Indicator LED
• 1 IR Sensor
• 2 Common Interface (CI) Slots
• 2 USB 2.0 host and device sockets
Power requirements:
• Mains input voltage: 90~260 VAC
• Mains input frequency: 50 / 60 Hz
• Power consumption:
• Normal use: 11-22W with Power Saving Standby mode
• Max: 60W
Physical Specifi cations:
• Size (W x H x D): 380 x 300 x 65mm
• Operating temperature: (+5)~(+40)°C
• Storage temperature: (-20) ~(+60)°C
Accessories:
• IR Remote Control unit
• Number of Batteries: 2 AAA (included)
• User's Manual
• Audio/Video Cable: 1 SCART cable
