VCR SCART connector (14). Select this option with the "OK" key (6) or "Left" and "Right" directional keys.
4.1.2.3. Aspect Ratio
Use this option to specify the screen ratio of the connected TV set. Select this option with the "OK" key (6) or "Left" and "Right"
directional keys.
4:3 – Select this option, if you have a standard TV with automatic format detection
16:9 – Select this option if you have a wide-screen TV
4:3 Letterbox – Select this option to convert a standard 4:3 video to 16:9. This is normally used to display a video in wide-screen
format on a standard TV that does not have automatic format detection.
4.1.2.4. Digital Audio Out
Use this option to specify desired audio type on the digital audio output (SPDIF). This option is valid for the optical and coax outputs.
Select this option with the "OK" key (6) or "Left" and "Right" directional keys.
4.1.2.5. OSD over VCR SCART
Use this option to specify if you want to have the OSD appear on the VCR SCART outputs. Select this option with the "OK" key (6)
or "Left" and "Right" directional keys.
Note:
This option is available only if TV SCART is set to RGB.
4.1.2.6. RF Modulator Audio
You can use this option to set the modulator subcarrier frequency, when using the RF modulator output. Select this option with the
"OK" key (6) or "Left" and "Right" directional keys.
5.5MHz – PAL system
6.0MHz – PAL I system
6.5MHz – SECAM system
4.1.2.7. RF Modulator Channel
Use this option to select modulator output channel. Select this option with the "OK" key (6) or "Left" and "Right" directional keys or
select this option with the OK key and enter the channel wanted.
4.1.2.8. Test Picture
Use this option to activate the test the picture on modulator output.
Select this option with the "OK" key (6) or "Left" and "Right" directional
keys.
4.1.3. Hard drive Settings
This is a place where you can format or set the basic parameters of the
built-in hard disk (see picture 16).
4.1.3.1. Format the hard disk
Warning: Picture 16
All stored data (recorded programmes in the library) will be lost during formatting.
If you have to format the built-in hard disk, you can do this from this menu by pressing the "Red" function key (8). A short warning
message will be displayed, waiting for confi rmation. In case you do not want to do format the disk press the "Red" function key (8)
or "Exit" key (22). In case you really want to format built-in hard disk press "Green" function key (9). After this, you will be asked
to enter a four digit pin code. If you enter an incorrect pin, "Wrong pin code" will be displayed. Press the "OK" key (6) or "Exit" key
(22) to turn return to the previous menu. Once the correct pin code is entered, formatting will begin immediately. You will then see
