EN
User manual - English
Unique device identifier (ID) of the product
Reference to China RoHS /
pollution control logo
Instruction for disposal of the device
Safety instructions
The instructions for use must be observed for safe
handling of the lamp
To avoid the risk of an electric shock, this device
must only be connected to a supply network that
has a protective earthing conductor.
This device is not designed for operation in envi-
ronments enriched with oxygen.
The lamp may only be used for the intended pur-
pose. Otherwise, the manufacturer will not be lia-
ble for personal injury or damage to property.
Use only the mains units (or transformers) ap-
proved or supplied by the manufacturer. Non-ob-
servance will void the conformity of the product
and release the manufacturer from any claims un-
der warranty.
Changes to the light are prohibited and will invali-
date the manufacturer's certificate of conformity
and all warranty claims.
Installation, maintenance and repair work may only
be carried out by the manufacturer or by specially
trained staff.
59131001
Maintenance must be carried out on the light at
least every two years
The unprotected human eye can be damaged by
direct light. Do not look directly into the light beam
of the lamp. Do not point the light beam at the pa-
tient's unprotected eye continuously.
When positioning the light body, there is a risk of
injury (e.g. crushing) and collisions with other ob-
jects (inventory) or walls.
Parts that fall off could injure the patient or lead to
an infection of the wound area.
Do not remove the rating plate or the warning la-
bels.
It is forbidden to carry out servicing or repair activi-
ties whilst the lamp is in use.
6 / 70
Operating the Mach LED 110 light
ON/OFF switch of the light (1)
1
Position the light arm using the
2
clamping lever on the cross
arm (2)
Position the light head using
the joint (3)
3
Positioning the light head at an
angle below 90 ° C is not per-
mitted, as there is a risk of the
joint (3) breaking
Mach LED 110
V1
2021-05-14
