Step 4:
Step 5:
Step 6:
All manuals and user guides at all-guides.com
Fix the left and right column (B) to the mainframe (A)
with inner hex pan head bolt (70), teeth washer (95) by
5# Allen wrench (65) .
Notice: Support the column with hand to avoid
falling down.
Fix the display to the column B with teeth washer (95)
and inner hex pan head bolt (70) by using 5# Allen
wrench (65) .
.
Fix the left and right bottom cover (23), (24) to the
mainframe with cross pan head screw M5*12 (86) by
solid wrench (66).
.
EN
5
