Endress+Hauser Promag 800 Index C Installationsanleitung Seite 9

Transmitter
Electrode cable
17 (0.67)
8 (0.31)
1
2
1
2
1
2
2
 1 Engineering unit mm (in)
A = Termination of the cables
B = Termination of the fine-wire cores with ferrules
1 = Red ferrules,  1.0 mm (0.04 in)
2 = White ferrules,  0.5 mm (0.02 in)
* = Stripping only for reinforced cables
Endress+Hauser
100 (3.94)*
80 (3.15)
50 (1.97)
A
B
GND
Coil current cable
90 (3.54)
70 (2.76)
50 (1.97)
8 (0.31)
1
 2 Engineering unit mm (in)
EA01338D
*
10 (0.39)
A
B
9
