7.3 Releasing and removing the connector cable
‣
 Switch off the power.
1 →
2.
1.
T20
7.4 Attaching the connecting cable to the transmitter
1.
4 x
3.
 3 Transmitter: main electronics module with terminals
1. Loosen the 4 fixing screws on the housing cover.
2. Open the housing cover.
3. Push the cable through the cable entry. To ensure tight sealing, do not remove the
sealing ring from the cable entry.
4. Strip the cable and cable ends. In the case of stranded cables, also fit ferrules →  8.
5. Connect the cable in accordance with the terminal assignment .
Endress+Hauser
2 →
E S
- C
+
-
2.
3
0,5 × 3,5 mm
1.
2.
3.
4.
6 5 7 8 4 37 36
EA01338D
4.
42 41
