‫ﺃﺩﺭ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﺑﺎﺗﺟﺎﻩ‬
‫ﺇﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬
.( H ) ‫ﻣﻡ، ﻋﻥ ﻁﺭﻳﻕ ﺟﻬﺎﺯ ﺍﻟﺗﺛﺑﻳﺕ‬
.(‫، ﻋﻥ ﻁﺭﻳﻕ "ﺍﻷﺳﻧﺎﻥ ﺍﻟﻠﻭﻟﺑﻳﺔ" ﺍﻟﻣﺿﻣﻧﺔ )ﻳﻣﻛﻥ ﻓﺻﻝ ﺟﻬﺎﺯ ﺍﻟﺗﺛﺑﻳﺕ‬
:( B ) ‫( ﻋﻠﻰ ﺍﻟﻌﺻﺎ ﺍﻟﺧﺎﺻﺔ ﺑﻪ‬
.‫ﺃﺩﺭ ﺍﻟﻣﻘﺑﺽ ﻓﻲ ﻋﻛﺱ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬
:‫ﺗﻡ ﺗﺣﺳﻳﻥ ﻋﻣﻠﻳﺔ ﺍﻟﺗﺭﻛﻳﺏ ﻟﺗﻧﺎﺳﺏ ﺃﻱ ﻧﻭﻉ ﻣﻥ ﺃﻧﻭﺍﻉ ﺍﻟﺩﻋﺎﻣﺎﺕ‬
55 ‫ﺇﻟﻰ‬ 1 ‫ﺫﺍﺕ ﺳﻣﻙ ﻳﺗﺭﺍﻭﺡ ﻣﻥ‬
.‫ﺿﻊ ﺍﻟﺟﺯء ﺍﻟﻧﺎﺗﺊ ﻣﻥ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﻋﻠﻰ ﻣﻧﺿﺩﺓ ﺃﻭ ﺳﻁﺢ ﻣﺳﺗﻭ ٍ ﺁﺧﺭ‬
.‫ﺃﺩﺭ ﻋﺟﻠﺔ ﺍﻟﺗﺛﺑﻳﺕ ﻓﻲ ﻋﻛﺱ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬
‫ﺇﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬
18\3
‫ﺗﺭﻛﻳﺏ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
A ) ‫ﻟﺗﺛﺑﻳﺕ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
:‫ﻟﻔﻙ ﻣﻘﺑﺽ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
‫ﻓﻙ‬
‫ﺗﺭﻛﻳﺏ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ‬
‫ﺍﻟﻣﻧﺎﺿﺩ ﺃﻭ ﺍﻟﻁﺎﻭﻻﺕ ﺃﻭ ﺍﻷﺭﻓﻑ‬
‫ﻛﺭﺍﺳﻲ ﺍﻟﺳﺑﺎﻕ‬
‫ﻁﺎﻭﻟﺔ‬ ‫ﺗﺭﻛﻳﺏ ﺫﺭﺍﻉ ﺗﺑﺩﻳﻝ ﺍﻟﺳﺭﻋﺔ ﻋﻠﻰ ﻣﻧﺿﺩﺓ ﺃﻭ‬
.‫ﺃﺩﺭ ﻋﺟﻠﺔ ﺍﻟﺗﺛﺑﻳﺕ ﻓﻲ ﺍﺗﺟﺎﻩ ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬
‫ﻓﻙ‬
1.
.‫ﻋﻘﺎﺭﺏ ﺍﻟﺳﺎﻋﺔ‬
2.
-
-
1 .
:‫ﻹﺣﻛﺎﻡ ﺍﻟﺭﺑﻁ‬ 2 .
:‫ﻟﻠﻔﻙ‬ 3 .
