roco Z21 signal DECODER Bedienungsanleitung Seite 64

Model Railway Control Unit
Signal-ID
decimal hex
160 0xA0
161 0xA1
162 0xA2
163 0xA3
164 0xA4
165 0xA5
166 0xA6
167 0xA7
168 0xA8
64
Name
ÖBB main signal Ep 4-6
Main signal of modern construction, with substitution
signal, movement forbidden cancelled, shunting for-
bidden cancelled and departure signal.
ÖBB distant signal
Four-aspect distant signal, with dark switching.
ÖBB semaphore main signal
Two or three-aspect semaphore main signal with light-
ing and double-assigned outputs for the coil drives.
Observe the information on semaphore signals under
https://www.z21.eu/en/products/z21-signal-decoder/
signaltypen
ÖBB semaphore distant signal
Two-aspect semaphore distant signal with lighting.
Observe the information on semaphore signals under
https://www.z21.eu/en/products/z21-signal-decoder/
signaltypen
ÖBB protection signal Ep 4-6
Protection signal of modern construction with substi-
tution signal and departure signal (optional).
ÖBB protection signal Ep 3-4
Protection signal, older construction with additional
outputs for substitution signal or 29b.
ÖBB shunting signal
Shunting signal of more modern or older construction
with additional output for the proceed signal.
ÖBB signal emulator
Signal emulator with additional outputs for substitu-
tion signal or 29b, as well as departure signal.
ÖBB brake test, departure
Brake test signal and departure signal, can be used
together or separately.
