CV Description
#211 DCC /DCC
basic ext
This CV can be used to set which signal aspect should be displayed after a DCCbasic swit-
ching command "1 Red" on signal 1.
255 = Specification in accordance with signal configuration
The DCC switching commands display the signal aspects as predefined in the signal
basic
configuration of the signal decoder selected via CV #41.
0 ... 254 = Explicit specification through user
If you wish to avoid specifications in the selected signal configuration, then you can enter
the DCC value here which accords with the required signal aspect. An explicit specifi-
ext
cation by the user may be expedient if, for example, the DCC system used does not yet
handle any DCC
for signals deviate substantially from those in the Z21 signal DECODER. In this case, the
Z21 signal DECODER can be adapted highly flexibly to the existing system.
Example: CV #211 = 16 ("Clear to proceed") ... Signal 1 then displays, after a DCC
switching command "1 Red" the signal aspect "Clear to proceed to".
You can also find the valid DCC
DCC basic switching commands of your signal in
versal" or under the link provided in
For explanations on the DCC
Operation on DCC control centres.
Factory setting: Specification in accordance with signal configuration
#212 DCC /DCC
basic ext
Corresponding with CV#211 for the DCC
#213 DCC /DCC
basic ext
Corresponding with CV#211 for the DCC
#214 DCC /DCC
basic ext
Corresponding with CV#211 for the DCC
#221 DCC /DCC
basic ext
to
Corresponding with CV #211 to #214 for the signal 2.
#224
#231 DCC /DCC
basic ext
to
Corresponding with CV #211 to #214 for the signal 3.
#234
#241 DCC /DCC
basic ext
to
Corresponding with CV #211 to #214 for the signal 4.
#244
#250 Decoder type
37 = ROCO 10837 Z21 signal DECODER

6.4 Resetting to factory status

If you want to set all settings back to the original status condition, keep the programming button held down until all LEDs are lit and
the blue LED is flashing. This means that all settings are reset and the reset has been initiated.
Alternatively, the value 8 can be written back to CV#8.
58
mapping for 1R, Signal 1
switching commands, and/or any switching sequences already available
ext
value range as well as the predefined assignment for the
ext
Appendix B – Signal
and DCC
basic ext
mapping for 1G, Signal 1
switching command "1 Green".
basic
mapping for 2R, Signal 1
switching command "2 Red".
basic
mapping for 2G, Signal 1
switching command "2 Green".
basic
mapping for Signal 2
mapping for Signal 3
mapping for Signal 4
Appendix A – Signal configuration "Uni-
configurations.
switching commands, see also the section
Range Default
0 - 255
basic
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
0 - 255
read only
255
255
255
255
255
255
255
37
