11.2006
4

Start-up

WARNING
Work must not be done on the module when the power supply is on or
the motor is turning.
The safety instructions for MASTERDRIVES are to be complied with.
♦ The standard converter start-up with "closed-loop speed control"
Prerequisites
♦ Check the existing board combination
♦ Determine the tachometer type
♦ Select and check the input terminals
♦ Establish and check the connection to the converter (refer to figs.
♦ Select the 24 V power supply for the tachometer
NOTE
"Potential separation" is required for the external supply.
♦ Check that the screen is grounded at both cable ends and that the
1)
Siemens AG 6SE7087-6CX84-3DB0
SIMOVERT MASTERDRIVES
has been completed.
• TSY in conjunction with CU1 (SIMOVERT FC)
• CU2 (SIMOVERT VC) / CUVC (Vector Control) /
1)
CUVP (Vector Control Compact PLUS)
HTL ↔ -X402 DTI
TTL ↔ -X401 DTI
5-1 and 5-2)
• SIMOVERT FC
↔ TSY -X113,-X117 ↔ CU1-X107 (15-V-
DTI -X403
Signalpegel)
• SIMOVERT VC
↔
DTI -X403 CU2 -X103
CUVC -X103
CUVP
• 0.3 A power supply module (option)
• Other 24 V power supplies
board is grounded.
only with 6SE7090-0XX84-3DB1
Digital tacho-Interface
(15 V signal level)
(15 V signal level)
1)
-X104 (15 V signal level)
Start-up
4-1
