Tab. 2 :
LED signalling
EN
34

Configurations

Status messages/LEDs

Two LEDs (Fig. 1 page 33) signal operational readiness (Tab. 2).
Red Green
illuminated –
– illuminated The IO module is online and ready for use
Flashes Flashes

Assign products to Hi-O groups

Using DIP switches, the Hi-O Technology™ products are assigned to two Hi-O
groups. The digital communication of the products always takes place exclusively
within the assigned Hi-O groups.
For example, the locks of a double-leaf door with separate monitoring of the
active and fixed leaf can be separately controlled via two separate IO modules.
Together with its IO module, a lock forms the Hi-O group 0, the other
Hi-O group 1, with its IO module ("DIP switch panel S3", page 40).
Rotary switch S1 – configuring external release
Via the unlock input the door is released for a configured time. With rotary switch
S1 the time response and, with a motorised lock, the unlocking/locking behaviour
is configured or with a coupling lock the coupling/uncoupling behaviour is
configured.
Position 0 – direct mode
Coupling lock
The lock
· couples the door handles when there
is a signal at the external release input,
· keeps the door handle coupled for as
long as the signal is present,
· uncouples the door handle if the
signal is no longer present.
Condition of the IO module
The IO module is offline
The IO module is offline or starting,
the automatic initialisation is running
Motorised lock
The lock
· is unlocked when there is a signal at
the external release input,
· remains unlocked as long as the
signal is present,
· activates the automatic locking if the
signal is no longer present.
