Procedure
1. Start the application.
2. Click User > Configuration and verify that the number of sensors in the configuration is the same
of the sensors installed.
3. Click Settings > Node ID Assignment.
4. Proceed according to the type of assignment:
If the assignment is...
manual
automatic
semi-automatic
Chain examples
X
Chain with controller at the end of the chain and a sensor
with termination connector
Save and print the configuration
1. In the application, click APPLY CHANGES: the sensors will memorize the inclination set and the
surrounding environment. The application will transfer the configuration to the controller, and
once transfer is complete it will generate a configuration report.
2. Click to save and print the report.
3. If necessary, complete the report with the inclination and height data of the sensors.
4. Require a signature by the authorized person.Ask the authorized person for a signature.
What to do next
Follow the instructions in the manual to validate the safety functions and manage the configuration.
www.inxpect.com/industrial/tools
SAF-MI-LBK-SBV-multi-v2.0-print-26000041 | © 2020-2021 Inxpect SpA
Then...
1. Click DISCOVER CONNECTED SENSORS to display the
connected sensors.
2. To assign a Node ID, click Assign for the unassigned Node ID
in the Configured sensors list.
3. To change a Node ID, click Change for the already assigned
Node ID in the Configured sensors list.
4. Select the SID of the sensor and confirm.
1. Click DISCOVER CONNECTED SENSORS to display the
connected sensors.
2. Click ASSIGN NODE IDS > Automatic.
Click ASSIGN NODE IDS > Semi-automatic and follow the
instructions displayed.
Y
Chain with controller inside of the chain and two sensors
with termination connector
Installation instructions
