(only for ISC-B01 controller) Synchronize the controllers
If there is more than one ISC-B01 controller in the area, refer to the system Instruction manual for the
multi-controller synchronization to reduce the interference among the controllers.
Define the area to be monitored
WARNING! LBK System is disabled during configuration. Prepare opportune safety measures
in the dangerous area protected by the system before configuring the system.
1.
Start the application.
2. For LBK System, click Login and Configuration. For LBK System BUS and for SBV System BUS,
click User and Configuration.
3. Define the area to be monitored and the sensor configuration.
Configure the inputs and outputs
1. In the application, click Settings.
2. Click Digital Input-Output and define the functions of the inputs and outputs.
3. If the muting is managed, click Muting and assign the sensors to the groups according to the
logic of the digital inputs.
4. Click APPLY CHANGES to save the configuration.
Install LBK-S01 sensors on the floor
Note: for installation with Metal protector kit (product code 90202ZAA), see the instructions supplied with
the kit.
1. Position the sensor as indicated in the configuration report and fasten the
bracket with two tamper-proof screws directly onto the floor or another
support.
NOTICE
: make sure the support does not inhibit machinery commands.
2. To tilt the sensor, loosen the side screws.
3. Direct the sensor up to the desired inclination.
Note: a notch is equal to 10° of inclination.
4. Tighten the screws.
Install LBK-S01 sensors on the machinery
Note: if the sensor is installed on parts that vibrate and objects are present in the field of view, the sensor
could generate undesired alarms.
1. Position the sensor as indicated in the configuration report and fasten the
bracket with two screws to a machinery support.
2. Loosen the side screws.
3. Position the sensor parallel to the machinery support.
Note: a notch is equal to 10° of inclination.
22
Installation instructions
Step
Step
SAF-MI-LBK-SBV-multi-v2.0-print-26000041 | © 2020-2021 Inxpect SpA
