Part
D Status LED
E Connectors for connecting the sensors in a chain and to the controller
LBK-S01 status LED
Status
Steady on
Rapid flashing on (100 ms)
Other conditions
SBV-01 sensors
D
Part
A Sensor
B Status LED
C Tamper-proof screws to position the sensor at a specific angle around x-axis (tilt 10°
steps)
D Perforated bracket for installing the sensor on the ground or on a wall
E Tamper-proof screw to position the sensor at a specific angle around y-axis (pan 10°
steps)
F Connectors for connecting the sensors in a chain and to the controller
G Tamper-proof screw to position the sensor at a specific angle around z-axis (roll 10°
steps)
SBV-01 status LED
Status
Steady blue
Flashing blue
Purple
Red
16 Installation instructions
Description
Sensor is working. No motion detected.
Sensor is detecting motion. Not available if the sensor is in muting.
Error
Description
Sensor is working. No motion detected.
Sensor is detecting motion. Not available if the sensor is in muting.
Firmware update conditions
Error conditions
