List of MIDI messages transmitted and received by the Legend '70s
Message Parameter
Program Program or sound
Change selection (*)
Pitch Bend Pitch wheel
When associated to FC1,
FC2 or modulation wheel.
Aftertouch
NB: this message is only
transmitted
CC 0 Bank Select MSB
CC 1 Modulation wheel
CC 3 Song Part selection
[FOOT CONTROLLER 2]
CC 4
pedal
CC 7 Module Volume (**)
CC 9 Mode Selection
[FOOT CONTROLLER 1]
CC 11
pedal
CC 12 E.PIANO On/Off
CC 13 E.PIANO Volume
CC 14 E.PIANO Timbre
CC 15 E.PIANO Bass
CC 16 E.PIANO Treble
CC 17 E.PIANO Tremolo On/Off
E.PIANO Tremolo
CC 18
Intensity
CC 19 E.PIANO Tremolo Speed
CC 20 E.PIANO Amp On/Off
CC 21 E.PIANO Output Routing
CC 25 A.PIANO On/Off
CC 26 A.PIANO Volume
CC 27 A.PIANO Timbre
CC 28 A.PIANO Dynamic
CC 29 A.PIANO Brilliance
CC 30 A.PIANO Output Routing
CC 32 Bank Select LSB
CC 33 CLAVI On/Off
CC 34 CLAVI Volume
CC 35 CLAVI Timbre
CLAVI Brilliant, Treble,
CC 36
Medium, Soft, C D, A B
CC 37 CLAVI Mute
CC 39 Clavi Output Routing
SOUND COLLECTION
CC 42
Part1 On/Off
SOUND COLLECTION
CC 43
Part1 Volume
SOUND COLLECTION
CC 44
Part1 Category
SOUND COLLECTION
CC 45
Part1 Timbre
SOUND COLLECTION
CC 46
Part1 Knob1 parameter
SOUND COLLECTION
CC 47
Part1 Knob2 parameter
SOUND COLLECTION
CC 48
Part1 Knob3 parameter
SOUND COLLECTION
CC 49
Part2 On/Off
SOUND COLLECTION
CC 50
Part2 Volume
SOUND COLLECTION
CC 51
Part2 Category
SOUND COLLECTION
CC 52
Part2 Timbre
* To select the internal sounds or Presets (Synth-8) of the module, Program Change messages must be received on the channel
associated by the Multi Channel mode (when active) or on the Alt-Keyb Channel (when active).
Value Range
In Global Channel:
1-128 Program selection
In Multi Channel and Alt-
Keyb Channel:
1-128 sound/Preset
selection
0-127
0-127
0-1 (See CC32)
0-127
0-3
0-127
0-127
0 Program Mode
1 Song Mode
0-127
≤63 off, ≥64 on
0-127
0-7
0-127
0-127
≤63 off, ≥64 on
0-127
0-127
≤63 off, ≥64 on
0-1 Main L-R
2 FX1
3 FX2
4 FX1+FX2
5 Aux1 Mono
6 Aux2 Mono
7 Aux1-2
≤63 off, ≥64 on
0-127
0-7
0-127
0-127
As E.PIANO Output Routing
When Bank MSB (CC0) = 0
0 Program Banks A-H
1 Program Banks I-P
When Bank MSB (CC0) = 1
0-8 Song List 1-9
≤63 off, ≥64 on
0-127
0-1
See CLAVI timbre controls
table
≤63 off, ≥64 on
As E.PIANO Output Routing
≤63 off, ≥64 on
0-127
0-7
0-X (number of timbres
depends on the family)
0-127
0-127
0-127
≤63 off, ≥64 on
0-127
0-7
0-X (number of sounds
depends on the family)
MIDI
Message Parameter
SOUND COLLECTION
CC 53
Part2 Knob1 parameter
SOUND COLLECTION
CC 54
Part2 Knob2 parameter
SOUND COLLECTION
CC 55
Part2 Knob3 parameter
SOUND COLLECTION
CC 56
Part1 Output Routing
SOUND COLLECTION
CC 57
Part2 Output Routing
CC 64 [SUSTAIN] pedal
CC 66 [FOOT SWITCH 2] pedal
CC 67 [FOOT SWITCH 1] pedal
CC 70 SYNTH-8 On/Off
CC 71 SYNTH-8 Volume
SYNTH-8 Knob
CC 72
parameter selection
SYNTH-8 [ASSIGN.1]
CC 73
knob
SYNTH-8 [ASSIGN.2]
CC 74
knob
SYNTH-8 [ASSIGN.3]
CC 75
knob
SYNTH-8 [ASSIGN.4]
CC 76
knob
CC 77 SYNTH-8 Output Routing
CC 78 REVERB Dry/Wet
CC 79 REVERB On/Off
CC 80 REVERB Type
CC 81 FX1 Switch
CC 82 FX1 Category
CC 83 FX1 Preset
CC 85 FX1 [TAP] parameter
CC 86 FX2 Switch
CC 87 FX2 Category
CC 89 FX2 Preset
CC 90 FX2 [TAP] parameter
CC 91 Module Reverb Send (**)
FX1 [AMOUNT]
CC 92
parameter
FX2 [AMOUNT]
CC 93
parameter
CC 94 FX1 [RATE] parameter
CC 95 FX2 [RATE] parameter
CC 120 All Sound Off (***)
CC 121 Reset All Controllers (***)
CC 123 All Notes Off (***)
- 3
MIDI Informations
Value Range
0-127
0-127
0-127
As E.PIANO Output Routing
As E.PIANO Output Routing
≤63 off, ≥64 on (switch)
0-127 (half damper)
≤63 off, ≥64 on
≤63 off, ≥64 on
≤63 off, ≥64 on
0-127
0-9
it depends on assigned
parameter
it depends on assigned
parameter
it depends on assigned
parameter
it depends on assigned
parameter
As E.PIANO Output Routing
0-127
≤63 off, ≥64 on
0-1 Rooms
2-4 Halls
5-6 Stages
7-8 Plates
9-10 Springs
11-12 Tapes
≤63 off, ≥64 on
0 Tremolo
1 Chorus
2 Flanger
3 Phaser
4 Wah
5 Amp
6 Delay
7 Others / PEQ3
8 Others / PEQ5
9 Others / GEQ5
10 Others / Comp
11 Others / Rotary
0-X (it depends on the number
of presets in each category)
0-127
≤63 off, ≥64 on
0 Tremolo
1 Chorus
2 Flanger
3 Phaser
4 Wah
5 Amp
6 Delay
7 Others / PEQ3
8 Others / PEQ5
9 Others / GEQ5
10 Others / Comp
11 Others / Rotary
0-X (it depends on the number
of presets in each category)
0-127
0-127
0-127
0-127
0-127
0-127
0-127
0-127
0-127
