Installation of 3 Blades:
Locate the marks to install 3 blades on the motor board.
Place the three blades without tightening them to the end at this point.
Screws
Blades
Installation
Mark "3"
Once the three blades are installed, adjust them so that the space between the
blades is minimal.
Now, tighten the screws to the maximum.
2 BLADES 3 BLADES
ATTENTION!
Be careful when assembling the parts, only one unassembled item
can slightly unbalance the fan. Please do not forget a single element, screws,
washers.
