8.2

Teileliste

Nr. Bezeichnung (ENG)
1 Main frame
2 Rear stabiliser
3 Adjustable round
wheel
4 Front stabiliser
5 Cover of front
stabiliser
6 Allen bolt
7 Bolt
7A Bolt
8 Curve washer
9 Spring washer
10L Left middle
supporting cover
10R Right middle
supporting cover
11 Upper decorative
cover
12 End cover
13 Seat post
14 Middle cable for
quick button
15 Bolt
16 Flat washer
17 Front post
18 Handpulse cable
19 Support of bottle
holder
20 Bottle holder
21 Bearing
22 Waved washer
23 Cross screw
24 C ring
25 Screw
40
Zeichnungsnummer
744S0-3-1000-J1
744S0-3-2112-J0
26000-6-1095-B0
744S0-3-2100-J0
734S0-6-2186-B0
50308-5-0040-F3
50108-5-0070-F4
50108-5-0110-F5
55108-3-2215-FA
55108-2-1520-FA
744S0-6-4551-B0
744S0-6-4552-B0
744S0-6-4520-B0
734S0-6-4514-B20
744S0-3-2200-J0
744S0-6-2543-00
50108-5-0015-F0
55108-1-1612-FA
744S0-3-2000-J0
744S0-6-2479-00
744S0-6-2292-B0
26100-6-1578-B0
58006-6-1040-01
55120-5-2705-DA
54203-2-0030-F0
55519-1-2312-DA
54203-2-0012-F0
Material

Spezifikation

D38*M10*1.5
Q235A+plastic
600*190.2*79.4
ABS
M8*1.25*40L
Q235A
M8*1.25*70L
35#
M8*1.25*110L
35#
D22xD8.5x1.5T
Q235A
D15.4xD8.2x2T
70#
366*79.4*118.9
ABS
366*76.1*118.9
ABS
629.3*170.6*114
ABS
191.9*172.1*138.4
ABS
550L
M8*1.25*15L
35#
D16*D8.5*1.2T
Q235A
2400L
168.6*168.6*45
ABS
D134*115
ABS
#6004-2RS(C0)
GCr15
D27*D20.3*0.5T
65Mn
M3*0.5*30L
Q235A
D22.5*D18.5*1.2T
65Mn
M3*0.5*12L
Q235A
Anz.
1
1
4
1
2
2
4
4
4
12
1
1
1
1
1
2
4
29
1
2
2
2
2
1
4
2
2
RB9.9
