TECHNICAL DATA RADIO CHARGER
Voltage..............................................................................................
Rated input .......................................................................................
Battery Voltage .................................................................................
Weight without packing and battery ..................................................
Tuning range AM ..............................................................................
Tuning range FM ..............................................................................
Charger output..................................................................................
Quick charge current ........................................................................
USB output .......................................................................................
Frequency band(s) of Bluetooth .......................................................
Maximum radio-frequency power transmitted
in the frequency band(s) ...................................................................
Charge Time
Li-Ion 18 V / 2.0 Ah ............................................................... about
Li-Ion 18 V / 4.0 Ah ............................................................... about
Li-Ion 18 V / 5.0 Ah ............................................................... about
Li-Ion 18 V / 6.0 Ah ............................................................... about
Li-Ion 18 V / 9.0 Ah ............................................................... about
Li-Ion 18V / 12.0 Ah .............................................................. about
Protection class ................................................................................
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
RADIO SAFETY WARNINGS
Never disassemble or modify this apparatus in any way.
Do not use this apparatus near water.
Clean only with dry cloth. Certain cleaning agents and solvents are harmful to plastics
and other insulated parts. Keep the apparatus handle clean, dry and free of oil or
grease.
Refer all servicing to qualified service personnel.
Do not install near any heat sources.
The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, table-cloths, curtains, etc.
No flame sources, such as lighted candles, should be placed on the apparatus.
It shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.
Do not place the product in closed bookcases or racks without proper ventilation.
Where the mains plug is used as the disconnect device, the disconnect device shall
remain readily operable.
Do not stand on unit.
Warning! To reduce the risk of fire, personal injury, and product damage due to a
short circuit, never immerse your tool, battery pack or charger in fluid or allow a fluid to
flow inside them. Corrosive or conductive fluids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can cause a short circuit.
CHARGER SAFETY WARNINGS
Do not dispose of used battery packs in the household refuse or by burning them.
Milwaukee Distributors offer to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Use only Milwaukee M18 System chargers for charging Milwaukee M18 System
battery packs. Do not use battery packs from other systems.
Caution! Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
The following battery packs can be charged with this charger:
voltage battery rated
capacity
18 V M18 B ≤ 1.5 Ah
18 V M18 BX ≤ 3.0 Ah
18 V M18 B2 ≤ 2.0 Ah
18 V M18 B4 ≤ 4.0 Ah
18 V M18 B5 ≤ 5.0 Ah
18 V M18 B6 ≤ 6.0 Ah
18 V M18 B9 ≤ 9.0 Ah
18 V M18HB12 ≤ 12.0 Ah
Do not try to charge non-rechargeable batteries with this charger.
No metal parts must be allowed to enter the battery section of the charger (short
circuit risk).
20 ENGLISH
M18 RC
..................... 220-240 V
............................ 230 W
.............................. 18 V
........................... 7,75 kg
................... 522-1620 kHz
.................... 87,5-108 MHz
.............................. 18 V
............................. 3,5 A
..................5,0 V / 2,1 A
................. 2402-2480 MHz
........................... 5,81 dBm
.............................. 45 min
.............................. 90 min
.............................110 min
............................ 120 min
............................ 180 min
............................ 240 min
............................... IP 54
Caution!
Risk of explosion if the battery is replaced by an incorrect type;
- high or low extreme temperatures that a battery can be subjected to during use,
storage or transportation,
- low air pressure at high altitude,
- replacement of a battery with an incorrect type that can defeat a safeguard (for
example in the case of some lithium battery types),
- disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a
battery,
- or leaving a battery in an extremely high temperature surrounding environment that
can result in an explosion or the leakage of flammable liquid or gas,
- or a battery subjected to extremely low air pressure that may result in an explosion
or the leakage of flammable liquid or gas.
Never break open battery packs and chargers and store only in dry rooms. Keep dry
at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new one.
Before use check machine, cable, and plug for any damages or material fatigue.
Repairs should only be carried out by authorised Service Agents.
This appliance is not intended to be used or cleaned by persons with reduced
physical, sensory or mental capabilities, or lack of experience or knowledge, unless
they have been given instructions concerning the safe use of the appliance by a
person legally responsible for their safety. They should be supervised whilst using the
appliance. Children shall not use, clean or play with this appliance, which when not in
use should be secured out of their reach.
SPECIFIED CONDITIONS OF USE
The radio charger can charge Milwaukee System 18 V batteries.
The radio is suitable for reception of broadcasting and to import audio sound of
different devices via Bluetooth and analog audio connection.
Via USB connection the radio can charge USB devices.
This radio is designed to withstand harsh operating environments as well as
unintentional drops.
Do not use this product in any other way as stated for normal use.
EC-DECLARATION OF CONFORMITY
Hereby, Techtronic Industries GmbH declares that the radio equipment type M18 RC
No. of is in compliance with Directive 2014/53/EU. The full text of the EU declaration of
battery conformity is available at the following internet address: http://services.milwaukeetool.
cells eu.
5
MAINS CONNECTION
2 x 5
Connect only to single-phase a.c. current and only to the system voltage indicated on
5
2 x 5 the rating plate. It is also possible to connect to sockets without an earthing contact as
the design conforms to safety class II.
2 x 5
2 x 5
3 x 5 BATTERIES
3 x 5
New battery packs reach full capacity after 4 - 5 chargings and dischargings. Battery
packs which have not been used for some time should be recharged before use.
Low Battery Indicator:
When the radio is powered by a battery pack and its charge falls below 10%, the low
battery indicator is displayed.
Battery Pack Protection:
To protect the life of the battery pack, the radio will shut off when the battery's charge
becomes too low. If this happens, plug radio charger to a mains connection and
charge the battery pack.
CHARACTERISTICS
After inserting the battery into the reception of the charger the battery will
automatically be charged (red lamp is illuminated continuously)
When a hot or cold battery pack is inserted into the charger (flashing red lamp),
charging will begin automatically once the battery reaches the correct charging
temperature (0°C...60°C).
Charging time varies depending on the battery temperature, charge needed and the
type of battery pack being charged.
If both LEDs flash at the same time, either the battery has not been completely
mounted or there is a fault in the battery or the charger. For safety reasons you must
stop using the charger and battery immediately and have them inspected by an
Milwaukee Customer Service Centre.
BLUETOOTH
Pairing
For first connection to a Bluetooth device, the Pairing must be performed.
Press the Bluetooth button .
If no Bluetooth device is connected, Bluetooth pairing will begin automatically and the
icon will flash on the display.
The radio will continue to search for a signal for 3 minutes.
To manually pair a device, press and hold Bluetooth button until the icon
begins to flash.
While the is flashing, select "Milwaukee" on the Bluetooth capable device.
On some devices you may need to enter PIN "0000".
Once the device has successfully paired with the radio, the will be shown on the
radio's display.
Connecting
Press the Bluetooth button .
When the radio locates a paired Bluetooth device, the will be shown on the radio's
display.
If connection is lost between the radio and the Bluetooth device, the radio will try to
reconnect automatically for up to 3 minutes.
Controlling
When streaming music through to the radio via a Bluetooth device, use the button to
start and pause the music. Use the ◄ and ► to move through the tracks.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods Legislation requirements.
Transportation of those batteries has to be done in accordance with local, national and
international provisions and regulations.
• The user can transport the batteries by road without further requirements.
• Commercial transport of Lithium-Ion batteries by third parties is subject to
Dangerous Goods regulations. Transport preparation and transport are exclusively
to be carried out by appropriately trained persons and the process has to be
accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated to prevent short
circuit.
• Ensure that battery pack is secured against movement within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

If the supply cord of this appliance is damaged, it must only be replaced by a repair
shop appointed by the manufacturer, because special purpose tools are required
Use only Milwaukee accessories and Milwaukee spare parts. Should components
need to be replaced which have not been described, please contact one of our
Milwaukee service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state the ten-digit No.
as well as the machine type printed on the label and order the drawing at your local
service agents or directly at: Techtronic Industries GmbH, Max-Eyth-Straße 10,
71364 Winnenden, Germany.
SYMBOLS
CAUTION! WARNING! DANGER!
Always disconnect the plug from the socket before carrying out
any work on the machine.
Please read the instructions carefully before starting the machine.
Do not dispose electric tools, batteries/rechargeable batteries
together with household waste material.
Electric tools and batteries that have reached the end of their life
must be collected separately and returned to an environmentally
compatible recycling facility.
Check with your local authority or retailer for recycling advice and
collection point.
Class II tool, tool in which protection against electric shock does
not rely on basic insulation only, but in which additional safety
precautions, such as double insulation or reinforced insulation,
are provided.
There being no provision for protective earthing or reliance upon
installation conditions.
Complete protection against contact, Protection against dust deposit
IP54
/ Protection from splashed water
This tool is only suitable for indoor use. Never expose tool to rain.
Do not burn used battery packs.
Never charge a damaged battery pack. Replace by a new one.
European Conformity Mark
British Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
ENGLISH 21
