IQ windowdrives
4.2

IQ windowdrive - F 1200+

Menu level 1
Drive Control
Parameters
Diagnosis
Menu level 2 Menu level 3
Open/Close Tilt Start/Stop
Open/Close Tilt Start/Stop
Open/Close Turn Start/Stop
Open/Close Turn Start/Stop
Speed Speed Opening Tilt
Speed Closing Tilt
Turn
Automatic
Stroke Stroke Tilt Vent.
Stroke Reversing
IQ gear Mode of operation push button
push button interface
Stop condition
Current Max. current open
Max. current close
Calibration current
-18 to -13 open
Times Display Auto.off
Drive Stop Mode
Special Functions LED Brightness
Proximity Sensor
Panel Key Mode
Turn function
Information Inputs
Positions
Obstacle info
Cycle Counter
Internal Value
Moved Distance
Operation Time
DataAnalyser LIN
Log Messages Current cycle
Last cycle
Erase current
Erase last
Data Drive Stop Mode
Control Unit
Menu structure
Menu level 4
see chapter 6.1
see chapter 6.2
see chapter 6.5
see chapter 6.9
see chapter 6.9
see chapter 6.9
Current Value
Signals [V]
Supply [V]
Brightness[V]
Current States
Turn blockage
current. Pos. [um] (Hallsensor)
abs. Pos. [um]
(Absolute position sensor)
HSK Pos. [mm]
(Position Main closing side)
Pos. [mm]
Drive direction Tilt/Turn
Tilt open (End pos.)
Tilt close (End pos.)
Block open. (End pos.)
Block close. (End pos.)
Cal. (End pos.)
Turn open (End pos.)
Cal. prox.1
Cal. prox.2
Cal. prox.3
Cal. pos.
Connected Drive
Moved Distance [m]
Connected Drive
Operation Time [h]
active
inactive
see chapter 7
Type
Serial number
Type
Serial number
HW-Revision
SW-Version
