8.4 Regulation of sun threshold
- Let down the awning, to be visible the signalation
that will be provide by the motor.
- Press PROG of a portable transmitter memorized
for about 4 sec, since the motor efects 2 upward
movements to signal the entry in " transmitter pro-
grammation". Issue the button PROG.
- Shortly press again "PROG" to enter in menu "
wind threshold programmation ". The numbers of
upward moviments efects from the motor is the
wind threshold actually programmed.
Issue the button PROG.
- Shortly press again "PROG" to enter in the menu "sun threshold programma-
tion". The number of upward movement efect from the motor is the sun thresh-
old actually programmed.
- If the sun threshold is that desired, expect without done any movements. After
about 8 sec the motor efects a numers of upward movements as the pro-
grammed threshold and the central unit turns back to the normal activity.
- If you want to change the threshold sun, press and issue the button STOP the
numbers of times as the threshold programmed. After about 8 sec from the last
pressure, the motor efects a numbers of upwards movements as the new pro-
grammed threshold and the central unit turns back to the normal activity.
9. RESTORE OF FACTORY CONDITIONS (reset)
- Take off supply voltage to the module.
- Keep press the button "2" on the body of the anemometer sensor, power the
central unit. The red led begins to flashing speedly.
- Keep press the button "2" for about 30 sec, since the motor efects 1 upward
movement and one downward to indicate the restore of the factory conditions
(both the led are switch on).
- Take off tension to the central unit and expect some seconds.
- Give again tension to the central unit.
10. EXPIRED
At the end of the cycle of the product, dispose as provided by local reg-
ulation. This product can be contain polluting substance for the environ-
ment and dangerous for health, is forbidden dispose the product with the
domestic waste.
11. FAQ AND PROBLEMS SOLUTION
? The central unit doesn't execute any operation.
- Verify that the central unit is correcty powered (between terminals N and L have
to be apply the supply voltage).
- As soon as it's powered, the central unit switch on 2 led shortly to signal that the
supply is regulary receipt to the central unit. If that couldn't happen, is probably
the presence of irreversible failure and could be necessary the replacement of
the central unit.
? When is press UPWARD of transmitter, the motor moves in downward.
- Take off supply to the central unit and reverse the wires at terminals D1 and
S1.
? When try to memorize the first transmitter, the motor efects 2 movements
downward.
- Be sure to have execute correctly the procedure of memorization (point 5.1).
- The procedure was execute too much slowly. At moment that the central unit
entries in " transmitter programmation " there are 8 sec to press the button STOP
of transmitter to memorize.
- Check that the batteries of the transmitter are load.
- Try to make the same operation with another transmitter.
ECLIPSE COMPACT_rev00
Soglia Velocità
sole sole
1 01 Klux
2 08 Klux
3 15 Klux
4 22 Klux
5 30 Klux
6 45 Klux
