In case that sun function is active (see point 7.2) the yellow led provides some sig-
nalations regarding the sun sensor:
- The yellow led is flashing speedly: the sun intensity is more high than the pro-
grammed threshold; if this condition remains at almost 2.5 minutes will be
ordered an downward movement.
- The yellow led is switch on fixed: the automatic manouvre of downward for pres-
ence of sun were executed.
- The yellow led is flashing slowly: the sun intensity is under the programmed
threshold; if this condition remains at least 18 minutes will be ordered an upward
manouvre.
- The yellow led is switch off: the automatic manouvre of upward for absence of
sun were executed.
7.2 Activation/desactivation of sun function
Is possible activate/desactivate the sun function using a portable transmitter
memorized in the central unit. The procedure of activation/desactivation of sun
sensor is describe in the transmitter instruction at point "sun function".
8. PROGRAMMATIONS FROM TRANSMITTER
Besides setting of "anemometer test" function and "sun" function, through any
other portable transmitter previously memorized can be done other operations
regarding the transmitter memorization and cancellation and the modify of wind
and sun sensor operation threshold.
8.1 Insert in memory of a new transmitter
- Take on the motor in intermediate position, so that to be visibles the movements
of motor signalationes.
- Press PROG of a portable transmitter memorized for about 4 sec, since the motor
efects 2 upward moviment to signal the entry in "transmitter programmation".
- Within 8 sec, press STOP of transmitter to memorize (in case of radio sensors
press the button indicated in the instruction of radio sensor).
- The central memorizes the code and signals the operation with a little upward
movement of the motor.
8.2 Cancellation from memory of a transmitter
- Take on the motor in intermediate position, so that to be visibles the movements
of motor signalationes.
- Press PROG of a portable transmitter memorized for about 4 sec, since the
motor efects 2 upward movement to signal the entry in "transmitter programma-
tion".
- Within 8 sec, press STOP of the transmitter to cancel (in case of radio sensors
press the button indicated in the instruction of radio sensor).
- The central unit cancels the code and signals the operation with a little down-
ward movement of the motor.
8.3 Regulation of wind threshold
- Let down the awning, to be visible the signalation that will be provide by the
motor.
- Press PROG of a portable transmitter memorized for about 4 sec, since the
motor efects 2 upward movements to signal the entry in " transmitter program-
mation". Issue the button PROG.
- Shortly press again "PROG" to enter in menu "wind threshold programmation".
The numbers of upward movements efect from the motor is the wind threshold
actually programmed.
- If the wind threshold is that desired, expecting without done any operations.
After about 8 sec the motor efects an numbers of
downward movements as the programmed thresh-
old and the central unit turns back to its normal
activity.
- If you want to change the wind threshold, press and
issue the button STOP the numbers of times as the
desire threshold. After about 8 sec from the last
pressure, the motor efects an numbers of upward
moviments as the new programmed threshold and
the central unit turns back to the normal activity.
12
Wind
threshold Velocity
1 10 Km/h
2 15 Km/h
3 20 Km/h
4 25 Km/h
5 30 Km/h
6 35 Km/h
