Connecting remotely via modem connection
Connecting remotely via modem connection requires the TELL GM-900 modem
and a SIM card capable for GSM data calls. For the modem connection, it is
necessary to have GSM data call (CSD) service enabled on both SIM cards,
the one installed in the modem, and the one in the device.
1. Launch the Compact GSM II programming software.
2. Click on the Modem tab, open the Serial port drop-down menu and note the
port numbers shown in the list.
3. Connect the TELL GM-900 modem to the computer, click on a different tab
and then back on the Modem tab. (The software will read the available serial
ports automatically when switching to the Modem tab.) Select the serial port
newly created by the modem in the drop-down menu (the one that was not
available earlier in the list).
4. Enter the device's phone number in the Phone number field, and then click
on the Connect button. You can follow the connection status in the Modem
communication details window. When the connection is established,
the CONNECT 9600 message is displayed and the login window pops up
automatically.
5. Enter the device password, and then click on the OK button.
6. After a successful authentication, the Read and Write buttons become
available in the program under the Settings tab.
7. Read the settings stored in the device by clicking on the Read button.
8. Configure the settings as needed, and then write the changed settings into
the device by clicking on the Write button.
9. When you have finished remote programming, click on the Disconnect
button to end the call.
