1.3 Preliminary checks

> Installation environment
ATTENTION
Do not spray water onto the motorisation.
Do not install the motorisation in an explosive environment.
Check that the temperature range marked on the drive is suited to the
installation location.
> Condition of the door to be motorised
Before installing the motorisation, check that:
- the door is in good mechanical condition
- the door is correctly balanced
- the structures of the garage (walls, lintel, partitions, ceiling, etc.)
enable the drive to be fixed securely. Strengthen these if necessary.
- the door can be correctly opened and closed manually using a force
of less than 150 N.
CAUTION: It is dangerous to perform any operation on the door springs
(the door may fall).
> Specifications of the door to be motorised
Make sure the parts of the door do not encroach onto the pavement or
public thoroughfare.
If the garage door is fitted with a wicket door, the door must be
equipped with a system that prevents it from moving when the wicket
door is not in the safety position.

1.4 Electrical installation

The installation of the power supply must comply with the standards
in force in the country in which the motorisation is installed, and must
be carried out by qualified personnel.
The electric line must be exclusively reserved for the motorisation and
equipped with protection, comprising:
- a 10 A fuse or breaker,
- a differential type device (30 mA).
An all-pole supply cut-off device must be provided.
It is recommended that you fit a lightning conductor (maximum
residual voltage 2 kV).
> Cable feed
Underground cables must be equipped with a protective sheath with
a sufficient diameter to contain the motor cable and the accessories
cables.
For overground cables, use a cable grommet that will withstand the
weight of vehicles (ref. 2400484).
Copyright © 2017 SOMFY ACTIVITES SA. All rights reserved.
DANGER
WARNING
DANGER

1.5 Safety instructions relating to installation

Before installing the motorisation, remove any unnecessary cords or
chains and deactivate any locking device (bolt) which is not required
for motorised operation.
Do not connect the motorisation to a power source (mains, battery or
solar) before installation is complete.
Ensure that any danger zones (crushing, cutting, trapping) between
the driven part and the surrounding fixed elements caused by the
opening movement of the driven part are avoided or indicated on the
installation (see the section "Danger zones").
Permanently affix the crushing warning labels near to any fixed control
devices, and so that they are extremely visible to the end-user.
Modifying one of the elements provided in this kit or using an additional
element not recommended in this manual is strictly prohibited.
Monitor the door as it moves and keep people away from it until
installation is complete.
Do not use adhesive to secure the motorisation.
Install the internal manual back release device at a height of less than
1.8 m.
Permanently affix the label concerning the manual back release device
near to its mobile component.
Take care when using the manual back release device as an open door
can suddenly fall off if the springs are weak, broken, or incorrectly
balanced.
ATTENTION
Install any fixed control device at a height of less than 1.5 m and
within sight of the door, but away from moving parts.
A er installation, ensure that:
- the mechanism is correctly adjusted
- the manual back release device is operating correctly
the motorisation changes direction when the door encounters an object
50 mm high on the ground.
> Safety devices
For operation in automatic mode or remote control, photoelectric
cells must be installed.
In automatic mode, the drive operates in at least one direction with no
intentional activation by the user.
For operation in automatic mode, or if the garage door faces a public
road, an orange light type signalling device may be required to comply
with the regulations in the country in which the motorisation is installed.
> Clothing precautions
Take off any jewellery (bracelet, chain, etc.) during installation.
For manoeuvring, drilling and welding operations, wear appropriate
protection (special glasses, gloves, ear protection, etc.).
WARNING
DANGER
WARNING
WARNING
WARNING
WARNING
