2.3 Reading and setting the comfort
temperature
The unit will strive for the most comfortable
supply air temperature based on the set comfort
temperature.
It is best to set the comfort temperature to the
same temperature as the room thermostat (of the
central heating system).
The comfort temperature can be set between
12°C and 28°C. How to read or set the comfort
temperature on the present operating device can be
found in the document of the operating device.
EN - 8
Description
Three numbers with a point after the second number are
displayed in the display.
The current setting of the comfort temperature is displayed.
The light above the icon with one arrow is lit.
The supply fan is turned off.
There is no supply of fresh air.
The light above the icon with two arrows is lit.
The supply fan is turned on.
There is balanced ventilation.
What to do
No action required.
Do not forget to turn on the
supply fan again when the supply
fan has been turned off manually.
No action required.
Action on Reaction on
display display***
1 Press and hold
for at
least 3 seconds
2
Press
Or press
3
Press
Explanation
Current set comfort
temperature is being
displayed.
Comfort temperature
is increased by 0.5°C.
Comfort temperature
is decreased by 0.5°C.
Comfort temperature
is confirmed and the
display returns to the
default screen.
