STANCE PHASE
STANCE FLEXION RESISTANCE
Factory setting = screw is at maximum resistance (most resistance to stance yielding) (Figure 8C)
Controls flexion of the knee during stance phase of gait. This adjustment is most effective for controlling resistance from stand-to-sit, stair or
ramp descent, and "stumble recovery."
SYMPTOM
Not Enough Flexion Resistance
Too Much Flexion Resistance
STANCE TRIGGER RESISTANCE
Factory setting = screw is at minimum resistance (easiest to trigger stance flexion) (Figure 10)
This sets the amount of toe load required to trigger release into flexion. If the knee goes into flexion too easily at higher walking speeds, this
adjustment may need to be increased.
SYMPTOM
Swing Flexion Triggered Prematurely
Swing Flexion Difficult To Trigger
(FIGURE 9C)
DESIRED RESULT
Increase Stance Flexion Resistance
Decrease Stance Flexion Resistance Turn
(FIGURE 9D)
DESIRED RESULT
Increase Trigger Resistance
Decrease Trigger Resistance Turn
SCREW ADJUSTMENT
S
Turn Clockwise
S
Counterclockwise
SCREW ADJUSTMENT
T
Turn Clockwise
T
Counterclockwise
