3.6 Performing a
measurement without
sampling hose
1. Remove the adapter from the gas inlet of
the analyzer with a 1/4 turn. Removal of
the Remote System
necessary!
Gas is drawn in through the inlet.
4

Dismantling the pump

1. Unscrew the screw (1) and remove the
pump.
2. Place the cap (2) on the spout.
3. Install the cover (3) to the Remote
System compartment of the analyzer.
Tighten the screw.
Dräger CMS Remote System
pump is not
Dismantling the pump
1
3
2
