Respekta GSP 60 IBA TiD MA++ Bedienungs- & Installationsanleitung Seite 70

2. If dishwasher is in stalled at the corner of the cabinet,
there should be some space when the door is opened.
NOTE:
Depending on where your electrical outlet is, you may need to cut a hole in the
opposite cabinet side.
Step 2. Aesthetic panel's dimensions and installation
for GSP 60 TiD MA++
The aesthetic wooden panel could be processed according to the The aesthetic wooden panel could be processed according to the
installation drawings. installation drawings.
Semi-integrated
Magical paster A and magical paster B be disjoinedon ,magical paster A on the
aesthetic wooden panel and felted magical paster B of the outer door of dishwasher
(see figure A). After positioning of the panel , fix the panel onto the outer door by
screws and bolts (See figure
A
Magical paster
Please adapt the
dimensions of the panel
to your kitchen furniture
GSP 60 IBA TiD MA++
model
B).
B
Magical paster
1.Take away the four short screws
2.Pin up the four long screws
22
Dishwasher Cabinet
Door of
dishwasher
Minimum space
of 50mm
