General
3.2

Survey and construction

1
9
1. Handle
2. Lifting eye
3. Battery-adapter cable with terminals
4. Vacuum pump
5. Pressure gauge
6. Air filter
7. Chain box
8. Suction plate
9. Wheel Set VPH-RS, allow to use the device by one person (optionally)
10. Stop for Wheel Set VPH-RS-AS, for large-size tiles (optionally)
3.3

Technical data

Type Carying capacity/WLL [kg] valve at 500 mbar under-pressure
VPH-100
52710008 / 51720009
4
5
6
7
8
100
2
10
3
V6
12 / 26
Dead weight [kg]
19
