Handle adjustment (TOPRO TAURUS E Premium)
Unscrew the locking wheel A until you can move the handle B forward and backward. Adjust the handle to the re-
quired angle. After adjusting the handle to the desired position, the locking knob must be tightened again.
NB: Be careful when unscrewing/tightening the lock wheel so that you do not hurt you fingers.
Hand brakes (TOPRO TAURUS E Premium)
Adjusting/controlling the brakes:
Unscrew the nut A. Tighten / loosen the brake wire with the adjusting screw B. Ensure that the brakes are working
properly and only touching the wheels when in use. Adjust the brakes evenly on both sides.
Important information:
Ensure that the brakes work properly before each trip. Inspect the brakes frequently by following the informa-
tion above. The walker wheels are made of a soft rubber, which gives an optimal braking capacity on slippery
floor. Wrong use can cause unsafe situations and damage to the walker: The walker must not be driven or
pushed with force when the parking brakes are on or when the wheels are partly locked using the brakes. This
indicates incorrect use and can cause wear and tear, which makes the tires and brake quality weaker.
Using the parking brakes:
Push the brake levers forwards D to activate the parking brakes. Be aware that the lever has some resistance before
it stops and locks the rear wheel. Pull the brake levers back to release the parking brakes
Using the driving brakes:
Pull the brake levers towards you C to reduce speed. It is a two-handed braking system, which means that you will
brake the rear wheel that is located on the same side as the brake lever. If you apply only one of the brakes, the walk-
er will turn to that side. When the lever is released, the braking will stop. Do not use the brakes continuously while
the walker is in motion.
Using the foot brakes // Using the directional block (model Premium)
TOPRO Taurus E Basic – all wheels / TOPRO Taurus E Premium – front wheels:
Step on the foot brakes on the rear wheels A or when required also on the front wheels B until you hear a clicking
sound. The wheels are now in a locked position C. To release the wheels, step on the top of the foot brake pedal for
it to rise again.
TOPRO TAURUS E Premium – rear wheels:
Step on the foot brakes on the rear wheels A once until you hear a clicking sound. The wheels are now in a direc-
tional blocked position E. Step on the foot brakes one more time until you hear a second click. The wheels are now
locked F. To release the wheels, step on the top of the foot brake pedal for it to rise again D.

Charging the battery

It is important to charge the battery on a regular basis to prolong the battery life. We recommend charging the bat-
tery every 24 hours. Regular charging will improve the performance of the battery. It takes approximately 5-8 hours
to fully charge the battery. Do not charge batteries at too high or too low temperatures.
Charging: Connect the charger to the power grid without the battery. There are two LED lights on the charger. The
yellow power-on-LED lights up when the charger is connected to power. As long as there is no battery in the socket,
the other LED light will not light up. Remove the battery from the control box of the walker A, by holding the battery
and turning it 45 degrees and lift it out. Please check that the contact surfaces are clean. Place the battery in the
charger by sliding it in and rotating it until it is pulled into place by the magnets. Check that one of the arrows on the
battery B points towards the white and blue mark/eye C. The LED will now turn blue. Once the charging is complete,
the blue LED will turn green, and it will remain permanently lit. To remove the battery from the charger, rotate it 90
degrees. It will then be ejected and be ready for use.
To mount the battery on the walker again put the battery back in the control box on the column. Check that one
arrow points towards the white and blue mark/eye and the other arrow points straight back D.
Tips and recommendations: If the battery's safety thermostat is activated due to overload, the battery must be
allowed to cool for at least half an hour before being charged or used again. A new battery may be inserted into the
controller after one minute. Always wait at least two seconds after the actuator has stopped before removing the
battery from the controller. Always use batteries which are in good condition and fully charged when inserted into
the controller.
