2. Front-facing installation (from 9 to 18 kg)
2.14
click
Hold the seat shell as illustrated
and position it on the base unit.
Press the seat shell downwards
until it clicks audibly into position.
2.15
0048-09
Always check that when the seat
shell is inserted a green dot is
visible on both sides through
the opening on the side pieces.
This indicates that the seat is
installed correctly.
Disassembly is done in the
reverse order (see 1.1 and 1.2).
To release the belt tensioner see
Chapter 5.
