Concord ultimax Einbau- Und Bedienungsanleitung Seite 38

2. Front-facing installation (from 9 to 18 kg)
2.9
1
Tighten the upper belt (1) slightly
and close the red belt clip (2).
Then tighten the belt once again.
2.10
0039-07
2
Use the ratchet to wind the belt
up until the base unit is firmly
secured in the car seat.
The belt must be taut.
The base unit must be
positioned straight on the car
seat, parallel to the direction
of travel. Move the base unit
to adjust if necessary and then
tighten the belt again.
2.11
0041-07
The car safety belt must be
threaded through all three belt
guides.
0244-01
0069-08
