Headlamp fairing
Notes
To remove the headlamp fairing, the rear-view
mirrors and side body panels must first be removed,
as described above.
Remove the instrument panel (1), taking it out of the
rubber retaining elements (2).
Disconnect the connectors of the parking light bulb.
Unscrew the two side screws (3) securing the headlamp
fairing to the headlamp bracket.
Notes
After refitting the headlamp fairing, refit the side
body panels and rear-view mirrors.
2
2
2
E
1
fig. 51
3
fig. 52
57
