Explanation of displays and buttons

13
12
11
10
Display
1
2 Menu keypad
3 UP button
4 STOP button
5 DOWN button
6 Channel selection button
Channel indicator lamps
7
34 - en
9
8
Manual/Automatic slide switch
8
9 Programming button
10 Battery compartment
11 Labelling field
12 RESET button (behind the la-
belling field)
13 Type plate
1
2
3
4
5
6
7
