Cable 2,3,5 and 6 are the module-connecting lines (190 mm) in the package.
•
Cable 4 is the module-connecting line (400 mm) in the package.
•
Main unit must be put in the top grid.
11. Pull the grounding line out and fixed its two end to the screw on the cover.
Figure 4-64 Connect the Grounding Line to the Cover
12. Use the hexagon wrench in the package fix the cover onto the gang box.
Video IntercomModule Door Station · User Manual
Figure 4-65 Fix the Cover
