DS-KD9203 Series
Face Recogni�on Door Sta�on
UD17874B-A
E N G L I S H
Diagram References
Appearance
1
1 2 3
Camera IR Supplement Light Screen
4 Loudspeaker 5 Bu�ons 6 Microphone 7 Card Reading Area
8 9
Fingerprint Recogni�on Module TAMPER
Note: The appearance of the device vary according to different model. Refers to the actual device.
Terminal
2
LAN: Network Signal Input COM1/COM2: Common Interface
NC1/NC2: Door Lock Relay Output (Normally Close)
BTN1/BTN2: Exit Bu�on Input
485A+/485A-: External RS-485 Card Reader NO1/NO2: Door Lock Relay Output (Normally Open)
485B+/485B-: External Elevator Controller
SEN1/SEN2: Door Contact Input
GND: Grounding DC 12 V: 12 VDC Power Input
Note:
The reserved port is used for debugging only.
Wiring descrip�on refers to the User Manual.
3 Installa�on
Before you begin:
1. Accessories that you need to prepare for installa�on: gang box.
2. Make sure the power supply meet the power requirements of the door sta�on (12 VDC, 2 A).
3. Make sure all the related equipment is power-off during the installa�on.
4. Wire the cables before installa�on.
Accessory
The dimension of the gang box is 364 mm (W) × 118 mm (H) × 40 mm (D).
The installa�on hole should be larger than the actual size. The suggested dimension of the
installa�on hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm (D).
Flush Moun�ng
1. Cave an installa�on hole on the wall. Pull the cable out from the wall.
Note:
The suggested dimension of the installa�on hole is 364.3 mm (W) × 118.6 mm (H) × 40.2 mm (D).
The suggested length of the cables le� outside is 250 mm.
2. Install the gang box into the wall.
a. Remove the plas�c sheet of the gang box with the tool.
b. Insert the gang box into the installa�on hole. Mark the gang box screw holes' posi�on with a
marker, and take out the gang box.
c. Drill 4 holes according to the marks on the wall, and insert the expansion sleeves into the screw
holes.
d. Fix the gang box with 4 expansion bolts.
3. Fix the gap between the gang box and wall with concrete. Remove the moun�ng ears with tool a�er
concrete is dry. Connect the cables according to the Wiring Descrip�on in User Manual.
4. Insert the door sta�on into the gang box. Slide the door sta�on down and fix it with 2 set screws.
Apply Silicone sealant among the joints between the device and the wall (except the lower side) to keep
the raindrop from entering.
Configura�on
4
Ac�vate Device
1
You are required to ac�vate the device first by se�ng a strong password for it before you can use the device.
1. Power on the device to enter the ac�va�on page automa�cally.
2. Create a password and confirm it.
3. Press # to ac�vate the door sta�on.
Note:
Enter an 8 to 16 characters admin password.
When entering the password, taking the numeric key 2 as example, press the numeric key 2 once, the text
field shows "2", and press it again in 1.5 s, the text field shows "a", and press it again in 1.5 s, the text field
shows "b", and so on.
Hold 0 to enter special characters.
Press # to confirm the password.
Press * to delete the password during entering.
Call Resident
2
The door sta�on can work as main/sub door sta�on, and outer door sta�on, which correspond to different
calling resident modes respec�vely.
Call from Main/Sub Door Sta�on
Press number bu�on to enter the calling page.
Enter the room No. and press call bu�on again to call.
Call from Outer Door Sta�on
Press number bu�on to enter the calling page.
Enter【Building No. + # + Unit No. + # + Room No.】 and press call bu�on to call resident.
Call Center
3
Press number bu�on to enter the calling page.
Press center bu�on to call. Press * to cancel during calling management center.
4 Unlock Door
The device support unlock the door by presen�ng card, entering password, and fingerprint. Here takes unlock
by entering password and unlock by presen�ng card for example.
Note: You should create the password and add the card to the device first.
Unlock by Entering Password
Common Password
Press number bu�on, enter【# + room No. + password + #】 to unlock the door.
Public Password
Note: Create the public password via iVMS-4200 Client So�ware remotely first.
Press number bu�on, enter【# + public password + #】 to unlock the door.
Unlock by Presen�ng Card
Present the card on the card reading area to unlock the door.
Appendix
5
1 Tips When Collec�ng/Comparing Face Picture
Keep your expression naturally when collec�ng or comparing face pictures.
Do not wear hat, sunglasses, or other accessories that can affect the facial recogni�on func�on.
Do not make your hair cover your eyes, ears, etc. and heavy makeup is not allowed.
In order to get a good quailty and accurate face picture, posi�on your face looking at the camera when
collec�ng or comparing face pictures.
Make sure your face is in the middle of the collec�ng window.
The recommended distance when collec�ng/comparing face pictures is between 400 mm and 500 mm.
Tips When Impor�ng Face Picture
2
Picture format: JPG.
Picture size cannot exceed 200 KB.
A pure background color is required. White is the best.
Note: The door sta�on can be configured via iVMS-4200 Client So�ware remotely.
Refer to Video Intercom Face Recogni�on Door Sta�on User Manual (scan the QR code) for details.
1
1
2
3
4
5
6
7
3
118
84
364 280
Unit:mm
2
9
Reserved
8
40
4
Screws Mounting Ears
Set Screws
RS-485B
LOCK2
Reserved LAN
LOCK1
RS485A
3
2
Gang Box
AlARM IN
DC 12V
AlARM IN
1
Wall
