Version Control - Danfoss Optyma Plus OP-MPS Anleitung

Instructions
Designation system for the Optyma™ Plus range
OP - MPXM 034 ML P00 G
1 2 3 4 5
1 Application
M = MBP
L = LBP
2 Package
Condensing unit family: P = Plus
3 Refrigerant
T = R404A/R507,R455A,R454C,R448A/R449A,R452A
S = R134a, R513A, R1234yf
V = R454C, R455A, R452A, R404A/R507
4 Condenser
M = Microchannel heat condenser
5 Swept volume
Displacement in cm 3 : Example 034 = 34 cm
6 Compressor platform
(Such as DP/DX/DS = Fixed speed Reciprocating compressor)
7 Version
P00: Optyma™ Plus (see Version table)
8 Voltage code
G = 230V/1-phase compressor & fan
E = 400V/3-phase compressor & 230V/1-phase fan
Technical data
Condensing unit
Application Codes
114X3110 OP-LPVM016DPP00G
LBP 114X3201 OP-LPVM026DSP00G
114X3202 OP-LPVM034DSP00G
114X4243 OP-MPSM026CSP00G
114X4244 OP-MPSM030CSP00G
114X4107 OP-MPTM008DYP00G
114X4111 OP-MPTM009DYP00G
114X4113 OP-MPTM012DPP00G
114X4114 OP-MPTM014DPP00G
MBP
114X4115 OP-MPTM018DXP00G
114X4237 OP-MPTM022DSP00G
114X4239 OP-MPTM026DSP00E
114X4238 OP-MPTM026DSP00G
114X4242 OP-MPTM034DSP00E
114X4241 OP-MPTM034DSP00G
© Danfoss | DCS (CC) | 2021.03
6 7 8
3
Electrical
Refrigerant Compressor
Model Code
G
G
G
G
G
G
G
G
G
G
G
E
G
E
G

Version control

Optyma™ Plus
Condensing unit :IP level
Refrigerant
Compressor technology
Control box (pre-wired E-panel)
Microchannel condenser
Fan speed controller
Main switch (circuit breaker)
Filter drier (flare connections)
Sight glass
Crankcase heater
HP/LP adjustable pressostat
Fail safe mini-pressostat
Access door(s)
Acoustic insulation
Condensing unit electronic controller
Network connectivity
Stack mounting
Oil separator
Discharge gas thermostat
Common alarm contact SPDT (HP/LP alarm)
Liquid injection kit
Electrical Box design
Adjustable time delay (Compressor)
Chassis/
Housing
V DPT16LA H1
V DST26NA H2
V DST34LA H2
S CS26TB H2
S CS30TB H2
T DLY80RAb H1
T DLY90RAb H1
T DPT12RA H1
T DPT14RA H1
T DX18TBa H1
T DS22TB H2
T DS26T3 H2
T DS26TB H2
T DS34T3 H2
T DS34TB H2
Group I / Group II
Reciprocating
Yes (inbuilt in controller)
Mechanical / Panel
Liquid Suction
Receiver
Valve Valve
(L)
Inch Inch
1.3 3/8" 3/8"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
1.3 3/8" 3/8"
1.3 3/8" 3/8"
1.3 3/8" 3/8"
1.3 3/8" 3/8"
1.3 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
3.4 1/2" 1/2"
118A2177A - AN37261897352601-010101 | 35
(P00)
IP54
Yes
Yes
Yes
Yes
Yes
Yes
Electronic
Yes
Yes
Yes
Yes
Yes
-
Yes
Yes
-
IP54
Yes
Unit Dimensions
(mm)
L W H
650 941 406
813 1090 480
813 1090 480
813 1090 480
813 1090 480
650 941 406
650 941 406
650 941 406
650 941 406
650 941 406
813 1090 480
813 1090 480
813 1090 480
813 1090 480
813 1090 480
