ENGLISH
OPERATION / CONTROL PANEL
"FRESCO 3000 RT" CAN BE USED BY ACTIVATING THE AIR CONDITIONING OR THE FAN FUNCTION
ONLY.
CONDITIONING (AC)
T 0 : TEMPERATURE SET BY USER
T amb : AMBIENT TEMPERATURE DETECTED BY PROBE
V 1 : COMPRESSOR ROTATION SPEED (2500 Rpm)
V 2 : COMPRESSOR ROTATION SPEED (4000 Rpm)
ON / OFF
When the system is switched off, pressing the ON / OFF button (see fig.1) for more than 2 seconds switches on
the AC system in STANDARD mode (V ) for a maximum of 6 consecutive hours and the half snowflake symbol
1
lights up.
If the system is switched on, pressing this button for more than 2 seconds switches off the AC system.
About 30" after switching on, the ventilation starts up automatically.
The display always shows the temperature set by the user (T 0 ).
The temperature which can be set by the user is between 17°C and 28°C.
MAX AC
When the system is switched on, (by default in STANDARD mode - V ) pressing MAX AC (see fig.1), the
1
maximum yield of the system is obtained by running the compressor at rotation speed V for 4 consecutive hours
2
and the full snowflake symbol lights up.
Once this function has been activated, press the MAX AC button again to return to speed V
1.
TIMER
In STANDARD mode, the operating hours envisaged by the timer are 6.
In MAX AC mode, the operating hours envisaged by the timer are 4.
If the system is switched on, every quick press of TIMER button (see fig.1) reduces the system operating time by 1
hour.
In MAX AC mode, this button can be pressed to reduce the compressor operating time at speed V from 4 to 1 in
2
steps of 1 hour.
13/38
