DESCRIPTION
1. MAIN SWITCHES (on-off / start)
2. PRESSURE SETTING KNOB
3. DEFLATION PORT (IN)
4. INFLATION PORT (OUT)
5. SAFETY FUSE
6. CABLE WITH ALLIGATOR CLIPS 12/24 V
7. INFLATION HOSE
TECHNICAL FEATURES
ITEM
TURBO MAX 12V
TURBO MAX 24V/S
TURBO MAX KIT 12V
TURBO MAX KIT 24V-EV
USE of TURBO MAX
ACCESSORIES AND POWER CABLES
·
TURBO MAX 12V and TURBO MAX 24V/S versions: inflation hose, adaptors and power
cable with alligator clips are located in the carry bag
·
TURBO MAX KIT12V and TURBO MAX KIT 24V-EV versions: the kit for permanent
installation is supplied with brackets, screws and a 50 cm-long power cable with a 100 A
cabled connector. The inflation hose is supplied on demand with standard valves fittings.
VOLTAGE AIR FLOW
(V) (L/minute)
11 ÷ 13 1000
22 ÷ 26 1000
11 ÷ 13 1000
21 ÷ 31 1000
MAX PRESSURE MAX CURRENT
(mbar)
250
250
250
250
Instructions manual
(A)
60
35
60
35
